Best Selling Customized Mobile Metal Car Carrier Transport Trailer Double Deck Auto Car Carrier Semi Trailer
| Quantity: | |
|---|---|
| Vehicle specifications | Specification of longitudinal beam | ||
| Vehicle outline (box size) | height | 420 (high-strength 700) bent part | |
| long | 17100 | Upper wing panel | 10*100 |
| wide | 2550 | Lower wing panel | 10*100 |
| tall | 3500 | Web plate | 6# |
| Vehicle configuration specifications | |||
| be generally called | Square tube (4 # high-strength 510) | traction pin | 50 pin type |
| Second floor | Second floor edge beam 6 # high-strength bending part | Outrigger | Simple leg support |
| Wheel block | 8 | Synchronous Valve | Imported WABCO |
| Punched plate | 2.75 # Punching Plate | ABS | WABCO 4S2M |
| Column | Bending piece 5 # manganese steel | air bag | AIR SUSPENSION SYSTEM |
| base | Punched plate | axle | BPW 2-axis 1950 |
| Toolbox | 2 of them | tire | 245/17.5-8 (triangle) |
| Spare tire rack | 2 of them | Steel ring | Factory standard -8 (Zhongtong) |
| air reservoir | 2 units of 40 liters and 1 unit of 50 liters | suspension | machinery |
| hydraulic pressure | Hydraulic lifting second floor | Lifting system | Spiral screw |
| Lamp LED | LED | power supply | 30 ㎡ |
| Vehicle specifications | Specification of longitudinal beam | ||
| Vehicle outline (box size) | height | 420 (high-strength 700) bent part | |
| long | 17100 | Upper wing panel | 10*100 |
| wide | 2550 | Lower wing panel | 10*100 |
| tall | 3500 | Web plate | 6# |
| Vehicle configuration specifications | |||
| be generally called | Square tube (4 # high-strength 510) | traction pin | 50 pin type |
| Second floor | Second floor edge beam 6 # high-strength bending part | Outrigger | Simple leg support |
| Wheel block | 8 | Synchronous Valve | Imported WABCO |
| Punched plate | 2.75 # Punching Plate | ABS | WABCO 4S2M |
| Column | Bending piece 5 # manganese steel | air bag | AIR SUSPENSION SYSTEM |
| base | Punched plate | axle | BPW 2-axis 1950 |
| Toolbox | 2 of them | tire | 245/17.5-8 (triangle) |
| Spare tire rack | 2 of them | Steel ring | Factory standard -8 (Zhongtong) |
| air reservoir | 2 units of 40 liters and 1 unit of 50 liters | suspension | machinery |
| hydraulic pressure | Hydraulic lifting second floor | Lifting system | Spiral screw |
| Lamp LED | LED | power supply | 30 ㎡ |
